H2C Combo Bambu Lab
| Item | Specifications | |
| Printing Technology | Fused Deposition Modeling | |
| Body | Build Volume (W*D*H) | Single Nozzle Printing: 325*320*320 mm³ (Left) Single Nozzle Printing: 305*320*325 mm³ (Right) Dual Nozzle Printing: 300*320*325 mm³ Total Volume for Two Nozzles: 330*320*325 mm³ |
| Chassis | Aluminum and Steel | |
Outer Frame | Plastic and Glass | |
| Physical Dimensions | Physical Dimensions | 492*514*626 mm³ Recommended Space for Printer: 700mm*700mm*1100mm |
| Net Weight | 32.5 kg | |
| Toolhead | Extruder Gear | Hardened Steel |
| Nozzle | Hardened Steel | |
| Max Nozzle Temperature | 350 °C | |
| Supported Nozzle Diameter | 0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm | |
Filament Cutter | Built-in | |
| Filament Diameter | 1.75 mm | |
| Extruder Motor | Bambu Lab High-precision Permanent Magnet Synchronous Motor | |
| Heatbed | Build Plate Material | Flexible Steel Plate |
Included Build Plate Type | Textured PEI Plate | |
| Supported Build Plate Type | Textured PEI plate, Engineering Plate | |
| Max Heatbed Temperature | 120 ℃ | |
| Speed | Max Speed of Toolhead | 1000 mm/s |
| Max Acceleration of Toolhead | 20,000 mm/s² | |
Max Flow for Hotend | 40 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature) | |
Chamber Temperature Control | Active Chamber Heating | Supported |
Max Temperature | 65 °C | |
Air Purification | Pre-filter Grade | G3 |
HEPA Filter Grade | H12 | |
Activated Carbon Filter Type | Granulated Coconut Shell | |
VOC Filtration | Superior | |
Particulate Matter Filtration | Supported | |
Cooling | Part Cooling Fan | Closed Loop Control |
Cooling Fan for Hotend | Closed Loop Control | |
Main Control Board Fan | Closed Loop Control | |
Chamber Exhaust Fan | Closed Loop Control | |
Chamber Heat Circulation Fan | Closed Loop Control | |
Auxiliary Part Cooling Fan | Closed Loop Control | |
Toolhead Enhanced Cooling Fan | Closed Loop Control | |
Supported Filament Type | PLA, PETG, TPU, PVA, BVOH, ABS, ASA, PC, PA, PET, PPS;Carbon/Glass Fiber Reinforced PLA, PETG, PA, PET, PC, ABS, ASA, PPA, PPS | |
| Sensor | Live View Camera | Built-in; 1920*1080 |
Nozzle Camera | Built-in; 1920*1080 | |
BirdsEye Camera | Built-in; 3264*2448 (Equipped with Laser Edition) | |
Toolhead Camera | Built-in; 1600*1200 | |
| Door Sensor | Supported | |
| Filament Run Out Sensor | Supported | |
| Filament Tangle Sensor | Supported | |
| Filament Odometry | Supported with AMS | |
| Power Loss Recovery | Supported | |
| Electrical Requirements | Voltage | 100-120 VAC / 200-240 VAC, 50/60 Hz |
| Max Power* | 1800 W@220 V/1250 W@110 V | |
Typical Power | 200 W@220 V/200 W@110 V (Single Nozzle Printing PLA) | |
Working Temperature | 10 °C-30 °C | |
| Electronics | Touchscreen | 5-inch 720*1280 Touchscreen |
| Storage | Built-in 8 GB EMMC and USB Port | |
| Control Interface | Touchscreen, mobile App, PC App | |
Motion Controller | Dual-core Cortex-M4 and Single-core Cortex-M7 | |
Application Processor | Quad-core ARM with NPU | |
| Software | Slicer | Bambu Studio Supports third-party slicers which export standard G-code, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported. |
| Supported Operating System | MacOS, Windows, Linux | |
Network Control | Ethernet | Not Available |
Wireless Network | Wi-Fi | |
Network Kill Switch | Not Available | |
Removable Network Module | Not Available | |
802.1X Network Access Control | Not Available | |
| Wi-Fi | Operating Frequency | 2412 - 2472 MHz, 5150 - 5850 MHz (FCC/CE) 2400 - 2483.5 MHz, 5150 - 5850 MHz (SRRC) |
| Wi-Fi Transmitter Power (EIRP) | 2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC) 5 GHz Band1/2: <23 dBm (FCC/CE/SRRC/MIC) 5 GHz Band3: <30 dBm (CE); <24 dBm (FCC) 5 GHz Band4: <23 dBm (FCC/SRRC); <14 dBm (CE) | |
| Wi-Fi Protocol | IEEE 802.11 a/b/g/n |
